Kannonaudio catalogue
System 100
A front-loaded horn system for large clubs and outdoor festivals, with touring and installation models.
4way sound system for linear sound system style
System100 is Kannonaudio's first speaker system.
It is designed for use at large clubs and outdoor festivals.
Through Kannonaudio's original uncompromising design and adjustment, System 100 reproduces soft and clear high frequencies and powerful low frequencies, as well as three-dimensional sound image expressiveness and extremely natural and organic sound.
System100's linear sound creates another dimension of sound space time.
Design details
This system uses a closed back cabinet front load horn.
System100 consists of treble + midrange Model101, mid-low range Model102, and bass range Model103, all of which use a closed back cabinet front-loaded horn.
Each of these System100 models is designed to be lightweight and compact so that it can be transported by one person, making it easy to transport, install, and save space. Venue with narrow entrances and venues with stairs going up and down can be easily installed by human power.
Model101, Model102, Model103 all have the same width and the sound axis is in the center of the front, so you can set up a smart appearance, and the time alignment is also corrected by the speaker processor. so sound engineer can easily align the entire sound axis.,It is designed so that it can be done.
The size of each model is designed to fit tightly into the truck bed.
Models in this family
Drawings and views
Cabinet designs, technical drawings and accessory views. Open any image at full size.
Specification source
Technical content and illustrations are taken from the original Kannonaudio workbook, worksheet “SYS100”. Confirm the specification for your order with Kannonaudio.
